Full Spectrum 2835 Strips|Full Spectrum LED Strips|

Address: 5F, BLDG A, Huilongda Ind. Zone, Shilongzai, Shiyan Town, Baoan Dist., Shenzhen, Guangdong, China

Tel: +86-755-29682086

Fax: +86-755-29682109

Skype: qlsales

prevnext: Full Spectrum 2835 Strips

LED Type: Full Spectrum SMD2835
Input Voltage: DC12V/DC24V
Color: Warm White (2700K/3000K), Nature White, Pure White
LED Qty: 60LED/m, 120LED/m
Beam Angle: 120 degree
IP Ratio: IP20, IP67 Version
IP20: Non-waterproof Version
IP67: With Silicone Tube
With 3M 300 strong adhesive tape on the backside
UL, CUL, CE, RoHS approved

Inquiry Wow Customer Question

※ Features

Features of QL Temperature Sensor Constant Current Strips:

● Constant current version: with stable current, suitable for high quality requirements project.

● DC12V/DC24V input: Can work with any DC12V/DC24V PWM control system.

● Can work with unstable power supply and without damage.

● with temperature Sensor: Can lower the current to protect itself when the temperature is too high.

● Brightness uniform: With same brightness from the first end to the last end for around 10m.

● DC24V version: can work with DC20V to DC30V Input

● DC 12V version: can work with DC10V to DC15V Input

※ Parameters

Model No.	Color	LED Qty	λ(Nm)/(CT:K)	Luminous Flux/m	PCB Size	Work Voltage	Power	Water proof	CRI

CV Version
QL-F835X30-W-12/24-FS	□Warm White	SMD 2835 60/m Super Bright	2700/3000K	950-1000	10mm	12V/24V	14.4W/m	IP20 /IP67	Full- Spectrum
QL-F835X30-N-12/24-FS	□Nature White		4000-4500K	1000-1050
QL-F835X30-P-12/24-FS	□Pure White		6000-6500K	1050-1100
QL-F835A60-W-12/24-FS	□Warm White	SMD 2835 120/m Super Bright	2700/3000K	1600-1700	10mm	12V/24V	19.2W/m	IP20	Full- Spectrum
QL-F835A60-N-12/24-FS	□Nature White		4000-4500K	1700-1800
QL-F835A60-P-12/24-FS	□Pure White		6000-6500K	1800-1900
CC Version
QL-F835X30-W-24C-FS	□Warm White	SMD 2835 60/m Super Bright	2700/3000K	950-1000	10mm	24V With IC	14.4W/m	IP20 /IP67	Full- Spectrum
QL-F835X30-N-24C-FS	□Nature White		4000-4500K	1000-1050
QL-F835X30-P-24C-FS	□Pure White		6000-6500K	1050-1100
QL-F835A60-W-24C-FS	□Warm White	SMD 2835 120/m Super Bright	2700/3000K	1600-1700	10mm	24V With IC	19.2W/m	IP20	Full- Spectrum
QL-F835A60-N-24C-FS	□Nature White		4000-4500K	1700-1800
QL-F835A60-P-24C-FS	□Pure White		6000-6500K	1800-1900
Remark: X is for Waterproof type. A for Non-waterproof, C for IP67
